| Colour |
Mushroom |
| Frame |
Advanced-Grade Composite front and rear triangles, 150mm Maestro Suspension, flip chip, integrated down tube storage |
| Fork |
Marzocchi Bomber Z1, 160mm, Rail damper, Boost, 15x110, Kabolt, tapered, 44mm offset, custom tuned for Liv |
| Shock |
Fox Float DPS Performance 185/55, custom tuned for Liv |
| Handlebar |
Giant Contact SL TR35, 35mm XS: 760mm, S:760mm, M:760mm, L:780mm |
| Grips |
Liv Tactal single lock-on XS/S: 120mm, M/L: 130mm |
| Stem |
Giant Contact SL, 35mm XS:40mm, S:50mm, M:50mm, L:50mm |
| Seatpost |
TranzX travel-adjustable dropper, remote
XS: 120-150mm travel / 30.9 x 459mm
S: 120-150mm travel / 30.9 x 459mm
M: 140-170mm travel / 30.9 x 499mm
L: 140-170mm travel / 30.9 x 499mm |
| Saddle |
Liv Sylvia |
| Pedals |
N/A |
| Shifters |
SRAM SX Eagle, 1x12 |
| Front Der. |
N/A |
| Rear Der. |
SRAM SX Eagle |
| Brakes |
Tektro M745, hydraulic, Tektro rotors
[F]203mm, [R]180mm |
| Brake Levers |
Tektro HDM-745 |
| Cassette |
SRAM SX Eagle, 11x50 |
| Chain |
SRAM SX Eagle |
| Crankset |
SRAM SX, 30t, 55mm chainline XS: 165mm, S:170mm, M:170mm, L:170mm |
| Bottom Bracket |
SRAM DUB, press fit |
| Rims |
Giant TR 1 29 WheelSystem |
| Hubs |
alloy, sealed bearing |
| Spokes |
Sapim |
| Tires |
[F] Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless [R, size M and L] Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, or [R, size XS and S] Maxxis Dissector 27.5x2.4WT, 3C Max Terra, EXO, TR, tubeless |
| Extras |
|
